Titan Grating

APPLICATIONS: Solar Screening | Facade Aesthetics | Privacy Partitions | Commercial & Industrial

Diagram of a gated compound or parking area with evenly spaced parking barriers, shown in section view.

Titan is engineered for applications requiring both structural performance and sleek design—perfect for sun shading, awnings, and access walkways. Supplied in pre-assembled panels for horizontal or vertical mounting, Titan combines strength with ease of installation.
Offering blade widths from 20mm to 40mm and a consistent 60mm spacing, Titan ensures ventilation and sun control while maintaining a bold façade presence. Made from aluminium with powder-coated or anodised finishes, this system is fully compliant with Australian Standards and includes a trafficable option for high-use areas.
Titan is the durable choice where strength and architectural style intersect.

PRODUCT DETAILS
Blade options 20mm, 32mm, 40mm
Blade thickness 3mm
Blade Spacing 60mm
Materials Aluminium
Finishes Powder-coated / Anodised
Testing Meets all relevant Australian Standard requirements
Options Trafficable
